Lithium Battery Protection Board BL-01
Our Lithium Battery Protection Board is a cutting-edge solution designed to maximize the safety and performance of lithium batteries. Lithium batteries are known for their high energy density, making them ideal for numerous applications. Our BMS board is meticulously engineered to cater to the specific demands of lithium batteries, offering unparalleled features and reliability.
Key Features of Lithium Battery Protection Board
High-Performance MCU
Efficient battery management with advanced microcontroller technology.
Sealing Glue Injection
Ensures waterproof, dustproof, and shockproof reliability.
High-quality MOS
3mΩ Ultra-Low Internal Resistance to minimizes power loss.
Compact size
Space-saving construction without compromising functionality.
Parameters of Lithium BMS Board
Model Number
BL-01
Supported Cell Type
Li-ion batteries, Lipo batteries, LifePO4 batteries
Voltage Range
3.2V - 4.2V
Current Rating
10A - 100A
Operating Temperature
-20°C to 70°C
Cell Count Supported
1S - 15S
Communication Interface
CAN, UART, or I2C
Balancing Current
50mA - 200mA per cell
Voltage Measurement Accuracy
±0.1%
Temperature Measurement Accuracy
±1°C
Overvoltage Protection Threshold
4.25V per cell
Undervoltage Protection Threshold
3.0V per cell
Short Circuit Detection Response Time
<1 millisecond
9 Major Protections on Lithium Battery Protection Board
Overvoltage Protection
Undervoltage Protection
Short Circuit Detection
Cell Voltage Monitoring
State-of-Charge Estimation
Thermal Management
Fault Diagnosis
State-of-Health Estimation
Communication Interface
Applications of Lithium BMS Battery Protection Board
Electric Vehicles (EVs)
Our lithium battery BMS board ensures the safety and performance of EV batteries with precise voltage control and advanced thermal management.
Renewable Energy Storage
Ideal for renewable energy systems, it maintains voltage levels, enhancing energy storage efficiency.
Portable Electronics
Our best BMS for lithium batteries enhances battery life and safety in smartphones, laptops, and wearables.
Drones and UAVs
Offers rapid fault detection and temperature control, ensuring reliable drone operations.
Electric Scooters
Optimizes lithium battery performance, extending the range and lifespan of electric scooters.
Electric Bicycles
Safeguards batteries in electric bicycles, enhancing ride reliability and battery longevity.
Electric Motorcycles
Lithium ion battery protection board provides precise voltage monitoring and protection for electric motorcycle batteries.
Electric Tricycles
Lithium bms system ensures the safety and efficiency of lithium batteries in electric tricycles.
Solar Street Lamps
Enhances the performance of lithium batteries in solar street lamps, maximizing energy utilization.
Types of BMS Boards
The BMS Boards offered by MOKOEnergy can be divided into more than 70 types according to the detailed classification.
FAQs of Lithium BMS Boards
A Lithium BMS is a crucial component for lithium-ion battery systems. It monitors, protects, and manages the individual cells within the battery pack to ensure safe and efficient operation.
A Lithium BMS helps prevent overcharging, overdischarging, and cell imbalances, ensuring the safety and longevity of your lithium-ion battery pack. It also provides real-time data for monitoring and maintenance.
Yes, our BMS board supports cell counts from 2S to 16S, making it suitable for a 4S battery pack.
Yes, our Lithium BMS is designed to work with various lithium-ion battery chemistries, including Li-ion, Li-Po, and LiFePO4, providing flexibility for different applications.
To install the Lithium Battery Management System (BMS) in your battery system, first ensure safety precautions are in place, including proper ventilation and safety gear. Consult the user manual for specific instructions, then connect the BMS balancing and power wires to the corresponding battery terminals, insulate and secure the connections, verify wiring and voltage, and power up your system. Regular monitoring and maintenance is necessary, and if you are unsure of any steps, it is recommended to seek the help of a professional to ensure a safe installation.
The Lithium BMS typically includes communication interfaces (e.g., RS232, RS485, CAN bus) for connecting to monitoring and control systems. You can use these interfaces to access real-time data and adjust settings as needed.
Yes, our Lithium BMS is adaptable and can be used for various battery pack sizes, from small-scale applications to large energy storage systems. It offers scalability to meet your specific needs.
Our board is certified with CE, RoHS, and UL (if applicable) to meet safety and quality standards.
